• a) Strip or isolated foundation excluding pile foundation with M-25 grade concrete and Fe-550 grade steel (SRMB) and SRMB/TATA/SELL Steel/JINDAL.
• b) Depth 1500bmm from Ground level as per drawing.
• c) Plinth 450 above ground level as per drawing.
• d) 100 thick PCC structural drawing submitted as per drawing.
• e) All work as per structural drawing submitted.

• a) R.C.C structure with specified grade of conc. & steel as per drawing.
• b) Parking floor ht. – 2850 (floor to floor) as per drawing.
• c) Other floor ht. – 2950 (floor to floor) as per drawing.
• d) 250/200/125 external brick work as per drawing.
• e) 12 mm thick internal plaster (4:1) as per drawing.
• f) 12 mm thick external plaster (4:1) as per drawing.
• g) LIFT machine room/stair room as per drawing.
• h) Elevation decorative as per submitted view. As per drawing.
• i) Care Taker room, toilet etc with parking arrangements.

Cement : Ultratech / Ambuja/JSW/BIRLA SAMRAT/NUVOCO Stone chips: 3/4 & 5/8 dn/ good quality available in local market. Sand: Yellow coarse for RCC and Medium for others Bishnupur, Burdwan. Bricks : Red brick/HOLO BRICKS.

• a) Sal wood door frames 100x80 for main door and 100x75 for others doors.
• b) Decorative embstro main door.(TYCOON /DURIAN/CENTURY)
• c) Internal doors water proof fenol flush door.
• d) Syntex door with Syntex frame – water proof, polished P.V.C. single sheet door.
• e) Main door fitting :
  • i) Godrej Dead bolt lock- latch.
  • ii) Tower bolt.
  • iii) 1 Nos. Magic eye.
  • iv) 1 Nos. Door stopper standard quality.
  • v) 1 Nos. Rubber buffer.
• f) Internal Doors :
  • i) Mortise lock with handle unit.
  • ii) Tower Bolt.
  • iii) Beading at door frames

• a) 1.4 mm uPvc (unpLasticised Polyvinyl Chloride) sliding (FENESTA) and 4 mm one- way black glass (Saint Gobind).
• b) M.S. Grill (SRMB) from outside using 18 mm sq.bar/19x6 flat bar as per design up to 18 kg. /sq.m black painted over 2 coat primer and paint.

• a) Concealed electrical wiring through PVC CONDUIT as per requirement.
• b) All switches are modular.
• c) 8/10 ways MCB for all circuits (Havells).
• d) Copper PVC insulted wires (Havells/ Finolex).
• e) Standered Modular main switch for each flat.
• f) Electrical arrangements for pump (CRI), & lift.
• g) Number of electrical point in each flat.

• Bed Room:
  • ▪️ 1 No. Fan point.
  • ▪️ 3 Nos. light point.
  • ▪️ 1 No. 15A plug socket on main switch board.
  • ▪️ 1 No. A.C. point.
  • ▪️ 1 No. T.V. point.
  • ▪️ Computer point.

• Drawing & Dining Room:
  • ▪️ 2 Nos. Fan point.
  • ▪️ 4 Nos. Light point.
  • ▪️ 2 Nos. 15A power sockets on main switch board.
  • ▪️ 1 No. T.V. cable point.
  • ▪️ 1 AC Point.

• Kitchen:
  • ▪️ 2 Nos. Light point.
  • ▪️ 1 No. exhausts fan point.
  • ▪️ 1 No. 5A plug socket on main switch board.
  • ▪️ 2 Nos. 15A plug socket.

• Toilet:
  • ▪️ 2 Nos. light point.
  • ▪️ 1 No. exhaust fan point.
  • ▪️ 1 No. 15A plug socket for Geyser (Two toilets).

Balcony: 1 No. Light point, 1 No. Fan point, 5A plug point.
Other: Calling bell point for each flat.
Staircase: 1 Light point in each landing with 2 ways switch.

• Car parking area/ Roof area/ Passage:
  • ▪️ 20 Nos. Light point including gate light with individual switch.
  • ▪️ 2 Nos. 15A & 2 Nos. 5A plug socket.
  • ▪️ 4 Nos. Fan point.

• a) Concealed Supreme Gold water lines with hot and cold facilities in all of each flat. (Supreme pipe) P.V.C.
• b) P.V.C. (Supreme) pipes for external water lines.
• c) High density (HDPE) P.V.C. pipes for waste and soil lines.
• d) P.V.C. (supreme make) 100mm dia rain water down pipe.
• e) JAQUAR C.P. fitting for all toilets in each flat.
• f) White vitreous sanitary fittings like JAQUAR.
• g) Aqua guard point, washing machine point and dining pedestal basin.
• h) 1 No. Toilet corner basin with bib cock and one pedestal basin at dining.
• i) 6” dia S.W. line with necessary manholes and master tarp etc.
• j) 13”x10’ digital glazed wall tiles/ vitrified tiles up to lintel height. (300/- per box)

• Toilet Fitting:
  • a) Jaquar Hanging Commode.
  • b) 1 No. basin with fitted with 2 Nos. angular stop cock (Marc).
  • c) 2 in 1 wall mixture with O.H. shower.
  • d) 1 No. Toilet loft.

• a) Black granite top over black stone support with S.S. sink (22x18).
• b) Glazed digital titles above cooking platform up to 3 ft height.
• c) 1 No. single bowl sink with waste and waste pipe.

• a) Bed room, dining/drawing and kitchen: 4x2 / Vitrified tiles flooring. (JHONSON)
• b) Toilet: Anti-skid tiles.
• c) white Marble flooring to stair floor and landing of entire flat.
• d) Parking area Kota stone/ anti-skid checker tiles, others area net cement.
• e) Water and heat proof treatment at roof.

• a) 1 No. UGR of required capacity as per HIDCO rules.
• b) 1 No. O.H. of required capacity as per HIDCO rules.
• c) 125 mm thick boundary wall of 1500 m ht with necessary foundation.
• d) 3 Nos. grill gates of standard design at main entry as per sanction plan.
• e) 3’3” ht S.S. railing at all balconies and 3’3” ht S.S. railing at stairs.
• f) Grill as per sanction plan at balcony.

• a) 2 coats weather coat paint over primer at external surface. (Berger/ Asian paint/)
• b) Putty at internal surface. (Berger/Asian paint/)
• c) 2 coats distemper paint in parking area, stair area & care takers room.
• d) M.S. grill works 2 coats primer, 2 coats paint (Berger/Asian paint/Nerolac)
• e) White washes to lift room and lift well

• a) B.E. 2HP pump with CRI/Kirlosker.
• b) Water line from HIDCO supply to UGR land scrape to open area (Max 200 sq.ft.).
• c) 5 Passenger LIFT
• d) Calling bell from main gate to Darwans room.

• Following optional work can be done on extra cost:
  • a) Iron remover plant.
  • b) Modular kitchen to each flat.
  • c) Power backup.
